The provided text is a product page for a CAD software plugin called the Layer-Manager, which is designed to organize and sort layers into a hierarchical structure. This plugin is compatible with several major CAD programs, including AutoCAD Civil 3D and BricsCAD, and is priced at €280.00. The manufacturer, aRES Datensysteme, emphasizes that the software is made in Germany and includes flexible licensing options where network and single-user licenses cost the same. The text also mentions that the Layer-Manager works well with the manufacturer's other civil engineering applications, known as cseTools, and is available on the Cadsoma platform, which offers...

The provided text is an excerpt from a product page on a platform called Cadsoma, detailing the TRICAD MS Elektro / Electric 3D plugin developed by VenturisIT GmbH. This plugin, priced at €1,799.00, is designed to help users easily place electrical installation components in both 2D and 3D environments. Key features highlighted include the use of intelligent components, support for 3D busbars, and functionality for calculating cable tray filling and generating bills of quantities. The software is compatible with MicroStation and OpenBuildings Designer, and an optional Report Manager module allows for the creation and export of custom reports.

The provided text is a product page for a software plugin called TRICAD MS Sprinkler / Sprinklers 3D, available on the Cadsoma platform. This plugin is designed to facilitate the easy and compliant design of sprinkler systems according to VDS guidelines and FM standards, and it is compatible with programs like MicroStation and OpenBuildings Designer. Key features include automatic connection routines, tank and distributor configuration, and the ability to generate a bill of quantities for all components. Available for purchase at €1,799.00, the software can also be enhanced with add-on modules like ISO X for production isometrics and the Report...

The provided text describes a software plugin called TRICAD MS Sanitär / Sanitary 3D, which is designed for creating and assessing water supply and wastewater systems in both two and three dimensions. This module is compatible with design platforms like MicroStation and OpenBuildings Designer, and it costs €1,799.00. Key features include intelligent components, a built-in waste water calculation function, and the ability to export a bill of quantities for all parts, pipelines, and insulation. The software, last released in August 2023, also offers advanced tools such as gravity flow modeling and autorouting, with an optional report manager add-on for custom...

The provided text describes the TRICAD MS Lüftung / Ventilation 3D plugin, a CADSOMA offering designed for the comprehensive modeling and evaluation of ventilation systems. This building module facilitates the creation of complete ventilation systems using square, round, or oval pipes and is compatible with MicroStation and OpenBuildings software. Key features include a ventilation system configurator, definition of volume flow via a room stamp, and the generation of a bill of quantities for all components. Available for €2,199.00, the software supports model-based design, modification of complex systems, and integrates with optional modules like the report manager for exporting detailed parts...

The source provides a detailed overview of the TRICAD MS Heizung / Heating 3D software plugin, which is designed for the three-dimensional planning and evaluation of complete heating systems. This plugin costs €1,799.00 and is compatible with various platforms, including MicroStation and OpenBuildings Designer. Key highlights include integrated radiator design according to BDH EN 442, the use of intelligent components, and features like heating pipe network pre-dimensioning and comprehensive bill of quantities reporting. Developed by VenturisIT GmbH, the software features a report manager for creating customized parts lists and supports bidirectionality between drawing and calculation. The product information is presented...

The provided text describes TRICAD MS Architektur / Architecture 3D, a plugin designed to facilitate the conversion of 2D architectural plans into 3D models. This software is compatible with various design platforms, including MicroStation and OpenBuildings Designer, and is available for purchase at €249.00. Key functionalities highlighted include the creation of structural elements like walls, columns, and stairs, as well as the generation of building grids. The plugin aims to streamline workflows, especially for HVAC/MEP designers, by enabling quick creation and modification of building components. It is offered by VenturisIT GmbH through the Cadsoma platform, which centralizes various software solutions...

This document provides an overview of TRICAD MS Stahlbau / Steel Construction 3D, a software plugin for creating 2D and 3D staging and steelwork layouts. It highlights the software's compatibility with OpenBuildings Speedikon, MicroStation, and OpenBuildings Designer, and details its features like a sample database of staircases and ladders, threshold value verification, and the ability to export bills of quantities. The text also describes how the plugin enables users to design steel structures with simple routings, grid flooring, and predesigned elements, and mentions the optional Report Manager add-on for custom material bills. Finally, it notes that this plugin, developed by...

This document describes TRICAD MS Schema / Schematics P&ID, a plugin available on the Cadsoma platform designed for plant design. It enables users to create various flow diagrams, including block flow, process, and P&ID diagrams, in accordance with EN ISO 10628 standards. The software boasts features such as check routines, bill of quantities, cross-references, and optional database integration, though data is primarily stored in MicroStation Design files. Compatible with OpenBuildings Speedikon, MicroStation, and OpenBuildings Designer, this plugin, priced at €1,399.00, aims to streamline diagram creation with its comprehensive functionality. The document also highlights Cadsoma's role in offering a centralized platform...

This source describes TRICAD MS Piping 3D, a software plugin designed for efficiently modeling apparatus and pipeline systems in a 3D environment. The plugin, compatible with programs like MicroStation and OpenBuildings Designer, offers features such as auto-routing, a built-in pipe classes module, and bill of quantities generation. It facilitates detailed design processes, allowing users to create pipes, fittings, and bends, and dynamically add connectors like flanges or welds. Furthermore, the text highlights add-on modules like Report Manager for customizable material reports and a construction module for creating solid building models quickly. The plugin, developed by VenturisIT GmbH, is available for...
